9
b) Remove the two screws near the padlock
symbols. These hold the battery cover in
place.
NOTE
Do not remove the screws denoted with !
c) Use a small flat-head screwdriver to pry
open and lift the cover on the side where you
removed the strap.
d) Remove the cover then remove the o-ring.
Discard the o-ring.
e) Remove the battery by prying it loose with a
small flat-head screwdriver.
f) Replace the battery with the new one from
the kit. The battery should click in place.
Make sure to respect the correct polarity
of the battery: the “+” has to be facing
outwards.
CLICK
g) Position the new o-ring from the kit in the
groove around the battery, ensuring that it
sits towards the outer edge of the groove.
NOTE
Do not lubricate the o-ring! Lubrication
causes the o-ring to twist when the cover is
put over it, causing the watch to flood.
h) Position the cover onto the watch case and
press it down evenly. Ensure that in the area of
the screws the cover touches the watch case.
i) Keep the cover pressed onto the watch case
while hand tightening the two screws. Don’t
use excessive force while tightening. Ideal
torque is 12 N cm / 17 oz-in.
j) Reposition the strap which was removed in
step a). For best results put a drop of Loctite
331 onto the thread of the screw. Hand
tighten without using excessive force. Ideal
torque is 25 N cm / 35 oz-in.
WARNING
Mares reserves the right to refuse to
provide service under the warranty if the
maintenance instructions are not followed.
