16
d) Remove the cover then remove the o-ring.
Discard the o-ring.
e) Remove the battery by prying it loose with a
small flat-head screwdriver.
f) Replace the battery with the new one from
the kit. The battery should click in place.
Make sure to respect the correct polarity
of the battery: the “+” has to be facing
outwards.
CLICK
g) Position the new o-ring from the kit in the
groove around the battery, ensuring that it
sits towards the outer edge of the groove.
h) Position the cover onto the watch case and
press it down evenly. Ensure that in the area
of the screws the cover touches the watch
case.
NOTE
Do not lubricate the o-ring! Lubrication
causes the o-ring to twist when the cover is
put over it, causing the watch to flood.
i) Keep the cover pressed onto the watch case
while hand tightening the two screws. Don’t
use excessive force while tightening. Ideal
torque is 12 N cm / 17 oz-in.
j) Reposition the strap which was removed in
step a). For best results put a drop of Loctite
222 onto the thread of the screw. Hand
tighten without using excessive force. Ideal
torque is 25 N cm / 35 oz-in.
WARNING
Mares reserves the right to refuse to
provide service under the warranty if the
maintenance instructions are not followed.
4.3. WARRANTY
Mares products are guaranteed for a period of
two years subject to the following limitations
and conditions:
The warranty is non-transferable and applies
strictly to the original purchaser.
Mares products are warranted free from
defects in materials and workmanship:
components that, upon technical inspection,
are found to be defective, will be replaced free
of charge.
Mares S.p.A. declines all responsibility
for accidents of any kind that result from
tampering or incorrect use of its products.
Any products returned for overhaul or repairs
under warranty, or for any other reason, must
be forwarded exclusively via the vendor and
accompanied with a proof of purchase slip.
Products travel at the risk of the sender.
4.4. WARRANTY EXCLUSIONS
Damage caused by water seepage resulting
from improper use (e.g. dirty seal, battery
compartment closed incorrectly, etc.).
Rupture or scratching of the case, glass or
strap as a result of violent impact or blows.
Damage resulting from excessive exposure to
elevated or low temperatures.
Damage caused by the use of compressed air
to clean the dive computer.
4.5. HOW TO FIND THE PRODUCT
SERIAL NUMBER
To see the product serial number, enter the
INFO submenu.
• 5. DISPOSAL OF THE DEVICE
Dispose of this device as electronic waste. Do
not throw it away with regular rubbish.
If you prefer, you can return the device to your
local Mares dealer.
