Series DC Digital Controllers
24
As in Basic Mode, the min, max, and set soft keys are active during crosshead
movement. When the cycling sequence has ended and the test stand has
stopped at a load set point or travel distance set point, the limit condition may
be overridden by pressing and holding UP or DOWN for two seconds.
6.4.1 Dwell time
Dwell time is the amount of time, in seconds, for which the test stand stops at a
limit during a cycle sequence. When the test stand has reached a limit, a
counter will be displayed, shown as follows:
If the DWELL U and/or DWELL L settings are set to 0, the test stand will
immediately reverse direction upon reaching the corresponding limit, and no
counter will be displayed.
The cycle sequence may be interrupted before it has been completed by
pressing STOP. A soft key labeled RESET will appear as follows:
CYCLES: 00024
menu
S E T
m i n
m a x
DWELL: 0001.5
menu
S E T
m i n
m a x
