Mark-10 DC Series User Manual

Series DC Digital Controllers
28
5. Click APPLY after making any changes in the Gauge Port
Settings area.
3. Gauge settings (refer to the gauge’s user’s guide)
1. Set to automatic output of every sample.
2. Disable Mitutoyo BCD output.
4. Test stand settings
1. Set the baud rate to 115,200.
2. Set the Control mode to Console.
5. The Gauge Settings tab and all other gauge-related functions
cannot be used while MESURgauge is connected to the DC controller.
It is intended for use only when connected to a Mark-10 gauge
directly.

Mark-10 DC Series Specifications

General

Brand	Mark-10
Model	DC Series
Category	Controller
Language	English
