Series TT03 Digital Torque Gauges User’s Guide
9
8 SET POINT INDICATORS
8.1 General Information
Set points are useful for tolerance checking (pass/fail). Two limits, high and low, are specified and stored
in the non-volatile memory of the instrument and the primary reading is compared to these limits.
8.2 Configuration
To configure set points, select Set Points from the menu. The screen appears as follows:
Either one, two, or none of the set points may be enabled. To toggle between the clockwise and counter-
clockwise directions, press the DIRECTION key.
If two set points have been enabled, they are displayed in the upper left corner of the display. If only one
set point has been enabled, the word OFF” appears in place of the value. If no set points have been
enabled, the upper left corner of the display will be blank. When set points are enabled, the following
indicators are shown to the left of the primary reading:
the displayed value is greater than the upper
load limit (NO GO HIGH)
the displayed value is between the limits (GO)
the displayed value is less than the lower load
limit (NO GO LOW)
Note: Set point indicators reference the displayed reading, not necessarily the current live load.
SET POINTS
Upper Disabled
* Upper Enabled
5.00
Lower Disabled
* Lower Enabled
3.50
