11
STEREO MODE
(2 x system 1 or 2 x system 2 or 2 x system 4) through LINK XLR;
Instrument
XLR Input
LEFT Aux Input
DSP
AMPLIFIER
Satellite
AMPLIFIER
Sub
+
RIGHT Aux Input
Instrument
XLR Input
+
Link
LEFT RIGHT
XLR cable
