12
TECHNICAL DETAILS
system 1
ACOUSTICAL SPECIFICATIONS
Frequency response: 50 Hz- 20 kHz
Max SPL: 123 dB
Horizontal coverage angle: 120°
Vertical coverage angle: 30°
Satellite: 4x2.0”, 16 Ohm
Sub: 2 x 8”, 8 Ohm
INPUT/OUTPUT SECTION
Input connectors: Jack-XLR male-AUX
Output connectors: XLR female
Input sensitivity: -1.1 dBu (@1 kHz)
DSP PROCESSOR SECTION
Crossover frequencies: 180 Hz
Protections: Thermal, rms
Limiter: Soft limiter
Controls: Volume, EQ
AMPLIFIER
Total Power: 1400 W PEAK (@ 4 Ohm)
High frequencies: 400 W PEAK (@ 4 Ohm)
Low frequencies: 1000 W PEAK (@ 4 Ohm)
Total Power: 700 W RMS (@ 4 Ohm)
High frequencies: 200 W RMS (@ 4 Ohm)
Low frequencies: 500 W RMS (@ 4 Ohm)
Cooling: Convection
Power Connection: VDE connector
CABINET
Cabinet Material: multiply poplar
Handles: 1 top
Pole Mount/Cap: Yes
Colour: Black
PHYSICAL
Weight Satellite: 1 Kg
Weight SUB: 16 Kg
Fullrange Speaker Pole mount
Height: 1.35m (min) / 1.80 m (max) with horizontal sub
