ECO-SMART MODBUS-ADRESSE
Konguration
Protokoll Modbus RTU
Standardadresse 01
Bandrate 4800 bps oder 9600 bps
Datenlänge 8
Parität Keiner
Stopp Bits 1
Physikalische Ebene RS485 (two wire + GND)
Parameter
No.
Inhalt Serie Stan-
dard
Position
00 Strom zum automatischen Neustart 0/1 1 PCB
01 Heizregister gültig oder ungültig 0/1 0 Kontroller
02
Bypass Öffnungs-
temperatur X
5-30
19 PCB
03
Bypass Öffnungs-
temperatur Y
2-15
3 PCB
04
Abtau-Intervall 15-99
30 PCB
05
Abtautemperatur eingeben -9-5
-1 PCB
06
Abtauzeit 2-20
10 PCB
07
CO2 Sensor 0 / 80-250
0 = Kein CO2 Sensor
80 = 800 ppm, 250 = 2500 ppm
Empfohlene Einstellung = 1000 ppm
0 PCB
08
Modbus-Adresse 01-16
01 PCB
09
ERV AN/AUS 0-AUS 1-AN
PCB
10
Zuluftventilator-Geschwindigkeit
Ventilatorgeschwindigkeiten: 0=Stopp,
2=Geschwindigkeit 1, 3=Geschwindigkeit 2,
5=Geschwindigkeit 3, 8=Geschwindigkeit 4,
9=Geschwindigkeit 5,10=Geschwindigkeit 6,
11=Geschwindigkeit 7,12=Geschwindigkeit 8,
13=Geschwindigkeit 9, 14=Geschwindigkeit 10
PCB
11
Abluftventilator-Geschwindigkeit
Ventilatorgeschwindigkeiten: 0=Stopp,
2=Geschwindigkeit 1, 3=Geschwindigkeit 2,
5=Geschwindigkeit 3, 8=Geschwindigkeit 4,
9=Geschwindigkeit 5,10=Geschwindigkeit 6,
11=Geschwindigkeit 7,12=Geschwindigkeit 8,
13=Geschwindigkeit 9, 14=Geschwindigkeit 10
PCB
12
Zimmertemperatur
beobachteter Wert, zeigt Zahl minus 40 PCB
13
Außentemperatur
observed value, showing number minus 40 PCB
14
Ablufttemperatur
observed value, showing number minus 40 PCB
15
Abtautemperatur
observed value, showing number minus 40 PCB
16
extern AN/AUS-Signal
Abfragwert, 0=Aus, 1=An PCB
17
CO2 AN/AUS-Signal
query value, 0=off, 1=on PCB
18
Brandalarmsignal / Bypass / Abtau-
signal
Suchwerte:
B0 - 1 Brandalarm AN
B1 - 1 Bypass an
B2 - 1 Bypass aus
B3 - 1 Abtauen
PCB
