10
Register Assignment Range Default
CV 1 Address 00 - 22 3
CV 2 Starting voltage 0 - 255 2
CV 3 Acceleration delay 1 - 255 3
CV 4 Braking delay 1 - 255 3
CV 5 Max. voltage 1 - 255 255
CV 5
After entry of CV 6 (when programming with older 55015 units) function value in
the register to be programmed
CV 6 CV number of the register to be programmed
CV 29
Bit 0 = Direction of travel
Bit 1 = Number of speed levels (14/28)
Bit 2 = Mode of operation (digital / analog+digital)
Bit 5 = short / long address
0/1
0/2
0/4
0/32
4
CV 54
Hand-off function and “Back-EMF”
Bit 1: hand-off function
Bit 2: MTS Back-EMF
Bit 3: analog Back-EMF,
Bit 4: load-dependent chuffs
Bit 5: 0 = F1 constant / flashing
Bit 6: 0 = F2 constant / flashing
Bit 7: 0 = 2 / chuffs/revolution
Bit 8: automatic brake sounds and random standing sounds
0/1
0/2
0/4
0/8
0/16
0/32
0/64
0/128
2
