11
Register Assignment Range Default
CV 54
Hand-off function on: When operating with 55015, you can adjust direction and
speed for two seconds after selecting a moving loco without causing the loco
to stop.
CV 55 Reset 55
CV 60 Back-EMF: Max. adjustment factor 1 – 255 4
CV 61 Back-EMF: Adjustment frequency 0 – 255 16
CV 62 Back-EMF: Maximum adjustment 0 – 255 255
CV 67 – 94 programmable operating curve 1 – 255 **
** The speed table is always stored with 28 values that are programmed in CV 67 to CV 94. When operating with 14 speed
levels,everysecondvalueisskipped.Basicvaluesfortheprogrammabletable:8,16,24,32,40,48,56,64,72,80,88,96,104,
112, 120, 128, 136, 144, 152, 160, 168, 176, 184, 192, 208, 224, 240, 255.
