6
Important!
Thefeederwiresfromthelayouttothetrans-
formermustneverbepluggedintoahousehold
poweroutlet.Makesureyourchildrenareaware
ofthisdanger!
Conectingthewirefrom8590
Payparticularattentionwhendoingthis
5
4
2.2 Electrical Connections for a Feeder Track
Stripasmallamountofinsulationfromtheendsofthered
andbrownfeederwires,thatareincludedwiththe8590fee-
dertrack,andconnecteachofthesetotheterminalofthe
samecoloronthepowerpack.Theredwireisconnected
tofeedertrack’sterminalclipthatisconnectedtotherail
closesttothepowerpack.Thebrownwireisconnectedto
theotherterminalcliponthefeedertrack.Inthediagram
belowthefeedertrackasinstalledshowsthebrownwire
connectedtotheleftterminalclipandtheredwirecon-
nectedtotherightterminalclipofthefeedertrack.
red
brown
