Marquant 014439 - DESCRIPTION; TECHNICAL DATA; INSTALLATION

EN
38
AM receiver
Frequency 522–1620 kHz
Available sensitivity >45 dB at S/N = 26 dB
USB devices
USB memory Supports ver. 1.1 and 2.0
DESCRIPTION
1. Main unit (including holder)
2. Removable front
3. Decorative frame
4. Instructions
5. ISO connection (male connector) (A/B)
6. Removal tool (2)
7. External microphone
8. Storage case for removable front
FIG. 1
INSTALLATION
1. Removable front
2. Decorative frame
3. Holder
4. Screws (sold separately)
5. Dashboard
FIG. 2
FIG. 3
1. Put the holder (3) in the dashboard and
use the fasteners that suit the thickness of
the dashboard. Bend in the fastener to x
the holding sleeve in the dashboard.
2. Check before tting the decorative frame
(2) that it is right side up – the thicker
hooks should be at the bottom.
• Be aware of the risk of being distracted if
the product is used when driving. Lack of
concentration when driving can result in
serious trac accidents. It is always the
driver who is responsible for the safe use
of the vehicle.
• Do not use the product in dicult and/or
risky driving conditions, for example in
bad weather, dangerous or busy trac.
• Play with moderate volume. Very high
volume can make it impossible to hear
noise from the surroundings and trac,
which can result in trac accidents.
• Prolonged exposure to high volume
(especially in earphones) can cause a
permanent hearing impairment.
SYMBOLS
Read the instructions.
Approved in accordance with
the relevant directives.
Recycle discarded product
in accordance with local
regulations.
TECHNICAL DATA
Voltage 12 V
Output 4 x 40 W
Impedance 4 
Fuse 15 A
Audio part
Maximum output 4 x 40 W
Continuous output 4 x 28 W RMS
FM receiver
Frequency 87.5–108.0 MHz
Available sensitivity >15 dB at S/N = 30 dB
