BASIC FUNCTIONS
1. Removal of front panel
2. Volume control
3. On/O/Mute
4. Display
5. AUX input
6. USB port
FIG. 6
HOW TO USE
FASTENING AND REMOVING
FRONT PANEL
A. Fastening
B. Removal
FIG. 7
NOTE:
• Do not expose the removable front
panel to direct sunshine, heat or naked
ame. Do not exposethe front panel to
dust, rain, splashing or moisture.
• Store the front panel in its case.
• The front panel is sensitive to knocks
and blows.
• Do not touch the connectors on the main
unit or front panel – risk of damage
and/or contamination.
RESET
Press the reset button (A) if the product is not
working properly. The product is then reset to
default settings. The reset button is behind the
front, which is removed as per steps 1 and 2.
FIG. 8
• Allow a professional technician to install
the product if you do not have the
necessary know-how and experience.
• Contact the retailer if you have any
problems or are in doubt about the
installation.
CABLE CONNECTIONS
1. ISO connector
2. Back RCA outlet (Left) (Right)
3. Subwoofer
4. Antenna connector (sold separately)
5. Jack for external microphone (black)
FIG. 5
ISO connector – pin conguration
and colour coding
Pin Colour Function
B1/B2
Purple (+)
Purple/black (-)
Right back speaker
B3/B4
Grey (+)
Grey/black (-)
Right front speaker
B5/B6
White (-)
White/black (-)
Left front speaker
B7/B8
Green (+)
Green/black (-)
Left back speaker
A4 Yellow Battery (+)
A5 Blue
Connect to power
amplier system
control terminal or
automatic antenna
relay control terminal
(max 150 mA 12 VDC)
A7 Red
Ignition
(ACC mode)
A8 Black Earth
