Information is displayed when the remote controller is powered up.
07
Remote Screen Indicators
Note:
All indicators shown in the figure are for the purpose of clear presentation. But during the actaul
operation, only the relative function signs are shown on the display window.
Transmission Indicator
MODE display
TIMER ON display
FAN SPEED display
TIMER OFF display
Silence feature
display
ECO display(some units)
LOCK display
Temperature/Timer/Fan speed
display
Sleep mode display
Follow me feature display
Wireless control feature display
Low battery detection display(If flashes)
Displays when LOCK feature
is activated.
Lights up when remote
sends signal to indoor
unit
Displays the current
including:
mode,
Displays when ECO
feature is activated
LOW
MED
HIGH
AUTO
Displays selected fan speed:
This fan speed can not be
adjusted in AUTO or DRY
mode.
Fresh feature display(some units)
(No displays when Fresh feature is activated)
Displays the set temperature
by default, or fan speed or
timer setting when using
TIMER ON/OFF functions.
Temperature range:
o
o
o
17-30 C /62-86 F
Timer setting range:
0-24 hours
This display is blank when
operating in FAN mode.
(20-28 C)
(Model dependent)
