15CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
REAR PANEL FUNCTIONS
24. MAINS INPUT
Connects the amplier to the mains power
supply.
25. FX LOOP
Connect external FX pedals or a signal
processor here. The FX loop is post DSP in
the signal chain.
26. SPEAKER OUTPUT (CODE100H ONLY)
Connect a speaker cabinet here.
IMPORTANT - Do NOT connect a speaker
cabinet of less than 8 Ohm, and never use
CODE100H without a speaker cabinet
connected.
2624
25
