9CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
AMP ASSEMBLY TABLES
TABLE 1 - MAINS TRANSFORMERS
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I, K, L, Q, S, X 1 MAINS 230V ASSEMBLY TXMA-90053-01
BLUE BROWN
B, C, F, M, T, U 1 MAINS 120V ASSEMBLY TXMA-90053-01
BLUE BLACK
J 1 MAINS 100V ASSEMBLY TXMA-90053-01
BLUE WHITE
TABLE 2 - FRONT PANELS
MODEL QTY DESCRIPTION STOCK NO.
CODE100 N/A
TABLE - 5 MAINS INPUT FUSES
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I, K, L, Q,
S, X
2 FUSE 0219.315MXAP FUSE-90024
B, C, F, K, M, T, U 2 FUSE 0219.630MXAP FUSE-90025
TABLE 4 - KNOBS
MODEL QTY DESCRIPTION STOCK NO.
CODE100 2 SHORT, BROWN BODY, GOLD CAP
ENCODER
KNOB-90017
CODE100 6 SHORT, BROWN BODY, GOLD CAP KNOB-90018
TABLE - 6 MAIN SWITCH
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
UNIVERSAL 1 POWER SWITCH PS8A SWTM-90006
TABLE 3 - REAR PANELS
MODEL QTY DESCRIPTION STOCK NO.
CODE100 N/A
