28CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
SPARES LIST CODE100
STOCK NO. DESCRIPTION UOM QTY
LOGO-01210 MARSHALL LOGO, WHITE EA 1
FRET-90041 FRET CLOTH, BLACK MTR 1.0
HNDL-91004 HANDLE ASSSEMBLY EA 1
SPKR-00110 12” CUSTOM SPEAKER EA 2
CVER-00209 BLACK LEVANT COVERING MTR 1.0
FEET-90026 RUBBERT FEET (BIG) EA 4
KNOB-90017 SHORT, BROWN BODY, GOLD CAP ENCODER EA 2
KNOB-90018 SHORT, BROWN BODY, GOLD CAP EA 6
LCDW-00002 LCD WINDOW LENS EA 1
LCDD-00002 BIG LCM WITH FFC EA 1
PCBA-90049 FRONT PANEL PCB EA 1
PCBA-90008 FS HEADPHONE PCB EA 1
PCBA-90033 DSP PCB EA 1
PCBA-90034 BLUETOOTH PCB EA 1
PCBA-90008 POWER AMP PCB EA 1
PCBA-90032 SPEAKER OUTPUT PCB EA 1
PCBA-90031 BRIDGE PCB EA 1
TXMA-90053-01 MAINS 230V - A, D, E, H, I, K, L, Q, S, X EA 1
TXMA-90053-01 MAINS 120V - B, C, F, M, T, U EA 1
TXMA-90053-01 MAINS 100V - J EA 1
SKTM-90002 3 POLE IEC FULSED MAILS INLET EA 1
FUSE-90024 0219.315MXAP FUSE - A, D, E, H, I, K, L, Q, S, X EA 2
FUSE-90025 0219.630MXAP FUSE - B, C, F, K, M, T, U EA 2
SWTM-90006 POWER SWITCH PS8A - UNIVERSAL EA 1
