ENGLISH
and Master 2 can be assigned to any mode and
can be switched back and forth.
5. MASTER 1
Master 1 is used on all channels/modes by
default.
6. MASTER 2
To set a channel/mode to recall master 2, select
the channel and mode, push the master button
to engage master 2 and then switch out of the
mode. When you re-visit the mode, the amp
will automatically recall which master volume
control you were previously using.
7. MASTER SWITCH
Switch between master 1 and master 2 for
different volume settings on the same channel/
mode. The red led in the switch indicates that
master 2 is engaged. The light is off when
master 1 is engaged.
Note: pre-sets stored in the footswitch will
recall whether master 1 or master 2 was
selected. However, it will not recall the previous
level of the master volume control.
3.2
FRONT PANEL FUNCTIONS CONTINUED
9. PRESENCE
Adjusts the high frequencies of the power amp.
Increasing high frequencies adds more bite to
your sound.
8. RESONANCE
Adjusts the low frequencies of the power amp.
Increasing low frequencies adds more bottom
end giving you a fatter sound.
Warning: care should be taken to avoid over
exertion of the speaker cones in high resonance
settings.
Note: both the presence and resonance
controls are power amp controls and therefore
only have effect when playing through a
speaker.
15. INPUT JACK SOCKET
Connect your guitar here using a ¼” jack
instrument cable.
