3
1. INPUT jack
Use a good quality (screened) guitar cable to
plug your guitar in here.
2. Clean VOLUME control
When the OD Select switch is ‘out’, this
control adjusts the volume of the Clean
Channel. At low settings the sound will be very
clean with a bell-like ring. Turning this control
above half way will introduce a desirable,
bluesy distortion as the power amplifier is
driven into ‘crunch mode’.
3. OD (Overdrive) SELECT switch
Depressing the Overdrive Select Switch will
engage the Overdrive Channel.
4. Overdrive GAIN control
Turning up the Overdrive Gain Control will
increase the amount of distortion generated in
the Overdrive channel. Low gain settings will
produce classic rock and blues tones. Crank
the Gain for fat and aggressive sounds that are
perfect for soloing or hard rock and nu-metal
riffing.
MG15CD Front Panel Features
1 2 3 4 5 6 7 8 13 9 10 11 12
MG15DFX Front Panel Features
1 2 3 4 5 6 7 8 14 15 9 11 12
ENGLISH
10
