51
T -250.0 -200.0 1.5 1.7
-200.0 0.0 0.5 0.7
0.0 400.0 0.2 0.4
E -250.0 -200.0 1.0 1.2
-200.0 -100.0 0.3 0.5
-100.0 1000.0 0.2 0.4
R
1
0.0 200.0 1.7 1.9
200.0 1767.0 1.0 1.2
S
1
0.0 200.0 1.7 1.9
200.0 1767.0 1.1 1.3
B
1
600.0 800.0 1.5 1.7
800.0 1000.0 1.2 1.4
1000.0 1820.0 1.0 1.2
C 0.0 1000.0 0.5 0.7
1000.0 2316.0 1.5 1.7
XK -200.0 800.0 0.2 0.4
BP 0.0 800.0 1.9 2.1
800.0 2500.0 0.6 0.8
L -200.0 900.0 0.2 0.4
U -200.0 0.0 0.4 0.6
0.0 600.0 0.2 0.4
N -200.0 -100.0 0.8 1.0
-100.0 1300.0 0.3 0.5
CJC error outside of 23 ± 5°C is 0.05°C/°C
1. For thermocouple measure mode on B, R and S; round the specification up or down accordingly as there
is no resolution past the decimal point.
Table 17: RTD Read and Source
RTD Type Range (°C) Accuracy (°C)
Minimum Maximum Measure 4W/Source Measure 3W
PT385, 10 ohm -200.0 -80.0 1.3 2.5
-80.0 0.0 1.3 2.5
0.0 100.0 1.4 2.7
100.0 300.0 1.5 3.0
300.0 400.0 1.6 3.1
400.0 630.0 1.8 3.3
630.0 800.0 1.9 3.6
PT385, 50 ohm -200.0 -80.0 0.3 0.5
-80.0 0.0 0.4 0.7
0.0 100.0 0.4 0.7
100.0 300.0 0.4 0.7
