P/N 705-ST30-xx
(see legend below for xx(x) and yy)
SRPT30/xxx
1/10/03
SYMBOL DESCRIPTION PART NUMBER QTY
Capacitor, .01 mf 50v GMV disc Jetcon F7Z5U1C103Z-TR 217-104 1
LED INDICATOR,GRN,RECTANGULAR 323-2124 1
IND,LED,RED CMD57124A 323-7124 3
FILTER,RFI,10A 250VAC,50/60HZ 339-0006 1
GROMMET,3/8IDX5/8ODFOR7/16HOLE 400-0014 1
STRIP,QUIET SHIELD,6.00x.197 400-0600 1
GROMMET,FOR 3/8 400-2170 1
HSNG,MOD IV 4 POS 87499-7 AMP 417-0138 1
CONTACT,CRIMP,MOD-IV 87809-1 417-8766 4
ASSY,FEMALE SCREWLOCK 205817-1 420-0817 2
SCREW,2-56X.312,S.S. PH SC 420-2105 2
SCREW,M3 X 20,PHILLIPS PAN HEAD,SS 420-3720 4
SCREW,4-40X.312,S.S. PH 420-4105 2
SCREW,4-40X.375,S.S. PH 420-4106 4
SCREW,6-32X.750,S.S. PH 420-6112 2
RIV,1/8X.422L .126-.187GR CLOS 421-1111 8
4-40 X .187 S.S. HEX NUT 421-4007 2
4-40 KEP NUT 421-4008 2
6-32 KEP NUT 421-6008 5
SOUTHCO SHEET EDGE 6-32 421-6908 4
SCREW,SEMS 6-32 X 7/16" PAN PH.ST. 422-6107 18
#4 LOCK S.S. SPLIT 423-4002 6
#6 LOCK SPLIT 423-6002 6
STOFF,ALUM 1/4HEX X 1 1/2 6-32 441-0068 4
FILLER,REAR,SRPT-30 471-5385 1
PANEL,BACK,SRPT-30 471-5386 1
PANEL,TOP COVER,SRPT-30 471-5387 1
PANEL,BOTTOM COVER,SRPT-30 471-5388 1
PARTITION,SRPT-30 471-5389 1
Screw, 4-40 x 1/4" phillips pan head M/S Nickel Plated 500-004 4
Screw, 6-32 x 3/8" phillips pan head M/S nickel plated 500-022 2
Washer, Switchcraft #S1790-1 500-123 1
Flat Washer, Micro Plastics #FW250-062 nylon 500-164 1
Screw, 6-32 x 1/4" phillips pan head Black Zinc 500-183 24
Screw, 4-40 x 3/8" phillips oval head M/S black zinc 500-188 10
Keps nut 4 x 40 zinc 4CNKEOZ 500-199 4
Screw, SEMS 4-40x1/4 Phillips Pan Head MS Black Zinc 500-210 11
Screw, SEMS 4-40x3/8 Phillips Pan Head MS Black Zinc 500-211 4
Polytube, Manhatten#AF155A-20-yel 510-005 0
Grommet, 3/8" GC 11-292-C 510-031 4
Fuseholder, Littlefuse #342-004 510-072 1
Bushing, #B-312-250 black shorty Microplastic #22MP01015 510-113 1
Handle Assy., black w/black plated steel hdwe #1879-376-370 510-132 1
Fuse, 4 Amp., 3AG Littlefuse #312-004 510-204 1
Bumper, Bruce Plastics 0772-0014 black 510-205 8
Brackets, #6 Keystone 634 510-210 5
Control Knobs, #45KNO23 510-212 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
