P/N 705-ST30-xx
(see legend below for xx(x) and yy)
SRPT30/xxx
1/10/03
Control Knob, #ME450-2023 510-215 4
Fan, NMB 2410ML04WB40-P00 or ADDA #AD0612HS-A70GL 510-231 1
Flexible Grommet, Tyton FP/A (82' per roll) 510-246 1
Shrink-Tubing, 1/8" B2 Black 510-259 0.1
Spacer, 4-40 x 1/2 hex threaded Keystone 1450C 513-026 2
Spacer, 4-40 x 1/2 hex threaded insulated Keystone 1902C 513-040 4
Switch, slide DPDT Switchcraft 46206LR 530-001 1
Switch, toggle SPDT C&K 7101MYZQ or Apem #5636AB16 530-008 2
Switch, Rocker, Miniature,DPDT, Red Mouser #629-GRS402210 530-090 1
Connector, Tini-Jax Switchcraft 41 550-083 1
Connector Shell XLR Receptacle 550-155-2 4
Cable Assembly w/2 conn. KSM-2189-05" 586-115 1
Ribbon Cable 6" Digi Key #M3AAA1606R-ND 586-134 1
Cable Assembly, AC Connector to Fuseholder 586-194 1
Cable Assembly, AC Connector to Ground 586-195 1
CABLE ASSEMBLY, SRPT-30/40A MN HRNS(SBCM) 586-211 1
Cover,Two Stage Power Amplifier 700-226-61 1
FRONT PANEL, SRPT-30 700-250-44 1
SRPT-40A Audio Board 800-166A40A 1
RPT-30/SRPT-40 Pre-Amp Mixer(SBCM) 800-251A 1
TRANSMITTER SYNTHESIZER ASSY xxx Band 800-375ATxxx 1
RPU Transmitter I/O Board Assy (SBCM) 800-379AR 1
Power Supply, Switching 15V, 10 Amp 800-383A 1
Uses one of the following PA assemblies:
PA ASSY, xxx MHZ, yyW 800-388Axxx-yy 1
OR
PA ASSY, xxx MHZ, yyW 800-373Axxx-yy 1
Uses one of the following Front Panel Control & Meter Boards:
SRPT-30 FP CONTROL & METER BRD ASSY (SBCM) 800-389A 1
OR
SRPT-30 FP CONTROL & METER BRD ASSY (SBCM) 800-382A 1
14.5 VOLT STEP-UP REGULATOR 800-392A 1
CABLE, RF OUTPUT, SRPT-40A (SBCM) 949-0365 1
Cover Gasket 2/4-CH DSTL Drawing #A1D4040 REV 2 DB65112 0
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
2
