P/N 800-392A
(see legend below for xx(x) and yy)
14.5 VOLT STEP-UP
REGULATOR
1/10/03
SYMBOL DESCRIPTION PART NUMBER QTY
Open Top Two Circuit Shunt Molex 15-38-1024 550-182 1
PCB, 14.5 VOLT STEP-UP REGULATOR 800-392B 1
C1 TANTALUM, SMT, D, 100UF, LOW ESR 298-107-1 1
C2 CAPACITOR, SMT, 1206, 6800 PF, 5% 270-682 1
C3 Cap., Tantalum, SMT, Size B, 10uF, 16V,Kemet T491B106K016AS 298-106 1
C4 Cap., monolithic chip, 100 pf 50v 5% Kemet C1206C101J5GAC 270-101 1
C5 TANTALUM, SMT, D, 100UF, LOW ESR 298-107-1 1
C6,C7 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 2
C8 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
D1 DIODE, SMT, 1A, SCHOTTKY RECTIFIER 418-120 1
E1-E4 TERM,TURRET,2 SHLDR,.219,GOLD FLASH 413-1597 4
J2 RCPT, 20 POS, 2 ROW, R-ANG, PCB 417-2043 1
L1 INDUCTOR, SMT, POWER, 10UH 350-103P 1
L2 Inductor,SMT, 1812, 82nH, Coilcraft 1812SMS-82NJ 350-201 1
P1 Connector, 2 dual pin header (cut from 550-316) 550-191 1
P3 Conn,16-Pin (cut from 550-325) Right Angle 550-325-16 1
P4 Connector,Header 10 Pin RI-10-1 Unsheltered 5x2x1 550-269 1
R1 RESISTOR, SMT, 1206, 110K OHM, 1% 185-110K 1
R2 Resistor, 10K ohm 1/8 watt 1% chip Dale CRCW1206-10K 185-103 1
R3 Resistor, SMT, 1206, 6.81K Ohm, Dale CRCW1206-6.81K 185-6.81K 1
R4 Resistor, SMT, size 1206, 162K ohms, Dale CRCW1206-162K 185-162K 1
R5 Resistor, SMT, 1206, 39.2K ohm 1% Dale CWCR1206-39.2K 185-393 1
R6 Resistor, SMT, size 1206, 392 ohms, Dale CRCW1206-392 185-392 1
R7 Resistor, SMT, size 1206, 2.74K ohms, Dale CRCW1206-2.74K 185-2.74K 1
U1 IC, SMT, 1.5A STEP-UP REGULATOR 400-196 1
U2 IC, SMT, Regulator,Adjustable, 1.5 Amps,National LM317AEMP 401-317 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
