P/N 800-251A
(see legend below for xx(x) and yy)
RPT-30/SRPT-40
Pre-Amp Mixer
10/30/02
SYMBOL DESCRIPTION PART NUMBER QTY
Grounding Strap, RPT-30 Pre-Amp 700-250-15 1
PC Board, Pre-amp/Mixer RPT-30 REV-9520 800-251B 1
Loctite TAK PAK High Temp. Gel #49904 3gm tube 900-018 0
C1,C2 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 2
C3,C4 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 2
C5,C6 Capacitor, monolithic chip 27 pf 50v 5% Kemet C1206C270J5GAC 270-270 2
C7 Capacitor, 10 pf 5% NPO disc Pace F5NPO1C1OOJ-TR 255-100 1
C8 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 1
C9,C10 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 2
C11,C12 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 2
C13,C14 Capacitor, monolithic chip 27 pf 50v 5% Kemet C1206C270J5GAC 270-270 2
C15 Capacitor, 10 pf 5% NPO disc Pace F5NPO1C1OOJ-TR 255-100 1
C16 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 1
C17,C18 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 2
C19,C20 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 2
C21,C22 Capacitor, monolithic chip 27 pf 50v 5% Kemet C1206C270J5GAC 270-270 2
C23 Capacitor, 10 pf 5% NPO disc Pace F5NPO1C1OOJ-TR 255-100 1
C24 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 1
C25,C26 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 2
C27,C28 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 2
C29,C30 Capacitor, monolithic chip 27 pf 50v 5% Kemet C1206C270J5GAC 270-270 2
C31 Capacitor, 10 pf 5% NPO disc Pace F5NPO1C1OOJ-TR 255-100 1
C32,C33 Capacitor. electrolytic 22uF 25V Mepco 3073BA220T025JPA 219-200 2
C34-C37 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 4
IC1,IC2 Integrated Circuit, Signetics NE5532AN, Phillips 405-532 2
J1-J4 Connector, XLR Receptacle Insert Nuetrik#3FD-V-I-O 550-155-1 4
P1 Connector, 6 pin Molex angle header (cut from 550-163) 550-149 1
R1 Resistor, 2.21K ohm 1/4 watt 1% metal film Mepco SFR25 145-222 1
R2,R3 Resistor, 1.5k ohm 1/4 ohm 1% metal film Mepco SFR25 145-152 2
R4,R5 Resistor, 100k ohm 1/4 watt 1% metal film Mepco SFR25 145-104 2
R6 Resistor, 15k ohm 1/4 watt 1% metal film Mepco SFR25 145-153 1
R7 Potentiometer,25kohm linear taper PC mt Xicon/Alpha #31VQ403 100-143 1
R8 Resistor, 2.21K ohm 1/4 watt 1% metal film Mepco SFR25 145-222 1
R9,R10 Resistor, 1.5k ohm 1/4 ohm 1% metal film Mepco SFR25 145-152 2
R11,R12 Resistor, 100k ohm 1/4 watt 1% metal film Mepco SFR25 145-104 2
R13 Resistor, 15k ohm 1/4 watt 1% metal film Mepco SFR25 145-153 1
R14 Potentiometer,25kohm linear taper PC mt Xicon/Alpha #31VQ403 100-143 1
R15 Resistor, 2.21K ohm 1/4 watt 1% metal film Mepco SFR25 145-222 1
R16,R17 Resistor, 1.5k ohm 1/4 ohm 1% metal film Mepco SFR25 145-152 2
R18,R19 Resistor, 100k ohm 1/4 watt 1% metal film Mepco SFR25 145-104 2
R20 Resistor, 15k ohm 1/4 watt 1% metal film Mepco SFR25 145-153 1
R21 Potentiometer,25kohm linear taper PC mt Xicon/Alpha #31VQ403 100-143 1
R22 Resistor, 2.21K ohm 1/4 watt 1% metal film Mepco SFR25 145-222 1
R23,R24 Resistor, 360k ohm 1/4 watt 1% carbon film CF1/4-360K 145-364-1 2
R25,R26 Resistor, 1.5k ohm 1/4 ohm 1% metal film Mepco SFR25 145-152 2
R27,R28 Resistor, 100k ohm 1/4 watt 1% metal film Mepco SFR25 145-104 2
R29 Resistor, 15k ohm 1/4 watt 1% metal film Mepco SFR25 145-153 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
