P/N 800-166CM
(see legend below for xx(x) and yy)
Generic RPU Audio
Board Assembly
10/30/02
SYMBOL DESCRIPTION PART NUMBER QTY
PC Board, Audio RPT-2/15/30 REV-9526 800-166B 1
C1 Capacitor, 470 pf 50v 10% Y5P disc Jetcon F6Y5P1C471K-JT 253-471 1
C2 Capacitor, tantalum, 4.7 mf 16v Kemet T350B475K016AS 299-470 1
C3 Capacitor, 106 50V Radial Electrolytic SPG 515D106M050JA6A 219-106 1
C4 Capacitor, electrolytic 22uF radial 35V 219-220 1
C7 Cap.,.27 mf 100v 10% polypro CD MTC1P27K OR Bishop C21B274K 226-274 1
C9 Capacitor, electrolytic 220uF 25V radial NIC UVX1E221MPA1TD 219-221 1
C10 Cap., 68pF 5% 200V ceramic dipped Kemet C317C680J2G5CA 256-680C 1
C11 Capacitor, .0082 Mfd 2.5% 100v polypro Seacor PFWAB82OHGNE 215-822 1
C12 Capacitor, .01 mf 50v GMV disc Jetcon F7Z5U1C103Z-TR 217-104 1
C13,C14 Capacitor, electrolytic 220uF 25V radial NIC UVX1E221MPA1TD 219-221 2
C15 Capacitor, 470 pf 50v 10% Y5P disc Jetcon F6Y5P1C471K-JT 253-471 1
C16 Capacitor, .1 mf 100v 10% mylar Ohsung OSG2A104K BULK 217-103 1
C17 Capacitor, tantalum, 4.7 mf 16v Kemet T350B475K016AS 299-470 1
C18 Capacitor, 106 50V Radial Electrolytic SPG 515D106M050JA6A 219-106 1
C19 Capacitor, tantalum, 4.7 mf 16v Kemet T350B475K016AS 299-470 1
C20 Capacitor, .012 mfd 2.5% 100v polypro Seacor PFWAC120HGUE 215-123 1
C21 Capacitor, electrolytic 22uF radial 35V 219-220 1
C22 Capacitor, .012 mfd 2.5% 100v polypro Seacor PFWAC120HGUE 215-123 1
C24 Cap., 47pF 5% 200V ceramic dipped Kemet C317C470J2G5CA 255-470C 1
C25 Capacitor, .022 mfd 2.5% 100v polypro Seacor PFWAC220HGNE 215-223 1
C26 Capacitor, .0039 mfd 2.5% polypro Seacor PFWAB390HGNE 215-392 1
C27 Cap., 47pF 5% 200V ceramic dipped Kemet C317C470J2G5CA 255-470C 1
C28 Capacitor, .01 mf 50v GMV disc Jetcon F7Z5U1C103Z-TR 217-104 1
C29 Capacitor, 470 pf 50v 10% Y5P disc Jetcon F6Y5P1C471K-JT 253-471 1
C30 Capacitor, electrolytic 22uF radial 35V 219-220 1
C31 Cap.,.27 mf 100v 10% polypro CD MTC1P27K OR Bishop C21B274K 226-274 1
C32-C41 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 10
D1-D5 Diode, 1N4148 Philips 410-914 5
D6 Diode, General Instruments 1N4007 414-007 1
IC1 Integrated Circuit, SGS TDA1054M 401-054 1
IC2 Integrated Circuit, TI LM3900N 403-900 1
L1 Inductor, 387-150M 40000-150000 uH Aurora #47271-011 350-032 1
P1 Connector, 10 pin header (cut from 550-162) 550-123 1
R1 Resistor, 1k ohm 1/4 watt 1% metal film Mepco SFR55 1K 1%TR 145-102 1
R2 Resistor, 47k ohm 1/4 watt 1% metal film Mepco SFR25 145-473 1
R3 Resistor, 182 ohm 1/4 watt 1% metal film Mepco SFR25 145-181 1
R4 Resistor, 680 ohm 1/4 watt 1% metal film Mepco SFR25 145-681 1
R5 Resistor, 150 ohm 1/4 watt 1% metal film Mepco SFR25 145-151 1
R6 Resistor, 100k ohm 1/4 watt 1% metal film Mepco SFR25 145-104 1
R7 Resistor, 3.32k ohm 1/4 watt 1% metal film Mepco SFR55 145-332 1
R8 Resistor, 3.92k ohm 1/4 watt 1% metal film Mepco SFR25 145-392 1
R9 Resistor, 3.3 ohm 1/4 watt 1% metal film Mepco SFR25 145-030 1
R10 Resistor, 3.92k ohm 1/4 watt 1% metal film Mepco SFR25 145-392 1
R11,R12 Resistor, 100k ohm 1/4 watt 1% metal film Mepco SFR25 145-104 2
R13 Resistor, 332 ohm 1/4 watt 1% metal film Mepco SFR25 145-331 1
R14 Resistor, 8.25k ohm 1/4 watt 1% metal film Mepco SFR25 145-822 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
