Marti Electronics SRPT-40A

To Next Page

To Previous Page

P/N 800-166CM

(see legend below for xx(x) and yy)

Generic RPU Audio

Board Assembly

10/30/02

R15 Resistor, 3.92k ohm 1/4 watt 1% metal film Mepco SFR25 145-392 1

R16 Resistor, 33.2k ohm 1/4 watt 1% metal film Mepco SFR25 145-333 1

R17 Resistor, 220 ohm 1/4 watt 1% metal film Mepco SFR25 145-221 1

R19 Resistor, 2.21 meg ohm 1/4 watt 1% metal film (2.21 Meg 1%) 145-225 1

R20 Resistor, 475k ohm 1/4 watt 1% metal film Koa MF55D TR 145-474 1

R22 Potentiometer, 5k ohm cermet Bourns 3309P-1-502 101-502 1

R23 Resistor, 3.32k ohm 1/4 watt 1% metal film Mepco SFR55 145-332 1

R24 Resistor, 2.74K ohm 1/4 watt 1% metal film Mepco SFR25 145-272 1

R25 Resistor, 4.75K ohm 1/4 watt 1% metal film Mepco SFR25 145-472 1

R26 Potentiometer, 100K ohm cermet Bourns 3309P-1-104 101-104 1

R27 Resistor, 2.21K ohm 1/4 watt 1% metal film Mepco SFR25 145-222 1

R28 Resistor, 2.21 meg ohm 1/4 watt 1% metal film (2.21 Meg 1%) 145-225 1

R29 Resistor, 10 meg ohm 1/4 watt 5% metal film Mepco SFR25 145-106 1

R30 Resistor, 8.2 meg ohm 1/4 watt 5% carbon film 29SJ250 145-825 1

R31 Resistor, 221k ohm 1/4 watt 1% RN55D2213F 145-224-1 1

R32 Resistor, 22.1k ohm 1/4 watt 1% metal film Mepco SFR25 145-223 1

R33 Potentiometer, 100K ohm cermet Bourns 3309P-1-104 101-104 1

R34 Resistor, 10k ohm 1/4 watt 1% metal film Mepco SFR25 145-103 1

R35,R36 Resistor, 475k ohm 1/4 watt 1% SFR55 475K 1% 145-474-1 2

R37 Potentiometer, 1meg ohm cermet Bourns 3296Y-1-105 top adjust 104-105 1

R38,R39 Resistor, 1 meg ohm 1/4 watt 1% metal film Mepco SFR25 145-105 2

R40 Resistor, 2.21 meg ohm 1/4 watt 1% metal film (2.21 Meg 1%) 145-225 1

R41 Resistor, 562 ohm 1/4 watt 1% metal film Mepco SFR25 145-561 1

R42 Resistor, 2.21 meg ohm 1/4 watt 1% metal film (2.21 Meg 1%) 145-225 1

R44 Resistor, 8.25k ohm 1/4 watt 1% metal film Mepco SFR25 145-822 1

R45 Resistor, 2.74K ohm 1/4 watt 1% metal film Mepco SFR25 145-272 1

R47 Resistor, 100k ohm 1/4 watt 1% metal film Mepco SFR25 145-104 1

xx(x) = 15(0), 23(0), 25(0), 33(0),

45(0), or 95(0) depending on

model frequency band

yy = 20, 30, 50, or 60

depending on

model MAX power

Marti Electronics SRPT-40A - Page 74
