P/N 800-385A
(see legend below for xx(x) and yy)
SRPT40A Front Panel
Control & Meter Board
10/30/02
SYMBOL DESCRIPTION PART NUMBER QTY
PC BOARD, FRONT PANEL CONTROL AND METER, SRPT-40A 800-385B 1
B1,B2 Subminiature Lamp, Lumex IFL-LX2162-16T 510-196 2
C1,C2 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 2
C3 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C4 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C5,C6 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 2
J7,J8 CONN,HEADER 3 PIN 417-0003 2
M1 METER, 60 WATTS, VOLTS/AMPS, VU 030-046M 1
P1 CONN,HEADER,16-PIN,PCB MOUNT 417-1606 1
P2 Connector, 4 pin single header (cut from 550-214) 550-226 1
P4 CONN,HEADER,16-PIN,PCB MOUNT 417-1606 1
P5 Connector, 6 pin Molex header (cut from 550-162) 550-136 1
P5 Connector, 8 pin Molex header (cut from 550-162) 550-138 1
P7,P8 Open Top Two Circuit Shunt Molex 15-38-1024 550-182 2
Q1-Q4 Transistor, SMT, General Purpose,NPN, Motorola MMBT3904LT1 439-041 4
Q5 Transistor, SMT, Darlington, NPN, Mototrola MMBTA14LT1 420-141 1
R1-R14 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 14
R15 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 1
R16-R26 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 11
R27 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 1
R28-R32 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 5
R33 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 1
R34-R37 Resistor, SMT, Size 1206, 475 ohms, Dale CRCW1206-475 185-475 4
R38-R41 Resistor, SMT, size 1206, 182 ohms, Dale CRCW1206-182 185-182 4
R42,R43 Resistor, SMT, size 1206, 68.1 ohms, Dale CRCW1206-68.1 185-68.1 2
R44 Resistor, SMT, size 1206, 392 ohms, Dale CRCW1206-392 185-392 1
R45 Resistor, SMT, size 1206, 1.21K ohms, Dale CRCW1206-1.21K 185-1.21K 1
R46 Resistor, SMT, size 1206, 432 ohms, Dale CRCW1206-432 185-432 1
R47 Resistor, SMT, size 1206, 47.5K ohms, Dale CRCW1206-47.5K 185-47.5K 1
R48-R50 Potentiometer, 5k ohm cermet Bourns 3309W-1-502 103-502 3
R51 Potentiometer, 5k ohm cermet Bourns 3309P-1-502 101-502 1
R52,R53 Resistor, SMT, size 1206, 68.1 ohms, Dale CRCW1206-68.1 185-68.1 2
R54-R57 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 4
R58,R59 Resistor, 10K ohm 1/8 watt 1% chip Dale CRCW1206-10K 185-103 2
R60 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 1
R61 RESISTOR, 332 OHM, SURFACE MOUNT,+/-1%, 1/8W 185-332 1
S1 Switch, Dip, 4 Position, Right Angle, Apem DA04T 530-086 1
S2 Switch, rotary 10WA135 530-059 1
U1-U4 IC, 8-Bit Ser/Par In, Ser Out SR Phillips 74HC165D 401-165 4
U5 IC, SMT, 8-Bit Ser In, Par Out SR Phillips 74HC164D 401-164 1
U6 IC, Octal D Flip-Flop w 3-St Out Phillips 74HC374D 401-374 1
U7 IC, SMT, Regulator,Adjustable, 1.5 Amps,National LM317AEMP 401-317 1
U8-U11 IC, Inverter, Open-drain Gate 400-106 4
U12 ICSMT, Digital Pot,2 Ch,100K ohms,Analog Device AD8402AR100 408-402 1
U13 IC,OP-amp, General Purpose Analog Device OP295GS 400-295 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
