P/N 800-379AR
(see legend below for xx(x) and yy)
RPU Transmitter
I/O Board Assy (SBCM)
10/30/02
SYMBOL DESCRIPTION PART NUMBER QTY
Screw, 4-40 x 7/16" phillips pan head MS zinc plated 500-162 2
PC Board, STL/RPU Transmitter I/O Rev A 800-379B 1
C1-C6 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 6
C7-C9 Cap, monolithic chip, 22 pf 50v 5% KEMET C1206C220J5GACTR 270-220 3
J4 Connector, D-Sub 15 pin angle Keltron DNR-15PJL-SG 550-170 1
L1,L2 Inductor, SMT, Power, 0.68, Coilcraft DO3316P-681HC 350-196 2
L3-L9 Inductor, 10uH SMT DN12103JTR-ND DELEVAN 5% 330-024 7
P2 Connector, 8 pin Molex angle header (cut from 550-163) 550-176 1
P3 Conn,2x8 pin dual row header right angle cut from 550-217 550-211 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
