Marti Electronics SRPT-40A - Page 80

P/N 800-375ATxxx
(see legend below for xx(x) and yy)
Transmitter Synthesizer
Assembly xxx
10/30/02
SYMBOL DESCRIPTION PART NUMBER QTY
Transmitter Synthesizer Board Assy Generic (SBCM) 800-375AT 1
RPU/STL XMIT SYN SW VERSION 2 800-375ATSW2 1
150 MHz Band Model
U6 IC, VCO, 135-185 MHz 400-185 1
230 and 250 MHz Band Models
U6 IC, VCO, 215-265 MHz 400-265 1
330 MHz Band Model
U6 IC, VCO, 300-350 MHz 400-351 1
450 MHz Band Model
U6 IC, VCO, 430-480 MHz 400-480 1
950 MHz Band Model
U6 IC, VCO, 935-965 MHz 400-965 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
