P/N 800-375AT
(see legend below for xx(x) and yy)
Transmitter Synthesizer
Board Assy
1/10/03
SYMBOL DESCRIPTION PART NUMBER QTY
TAPE,KAPTON 1/4 700-0119 0
Exterior Fencing&Cover,Synth Leader Tech88-CBSU-2.25x5.75x.8 700-226-63 1
PC Board, Transmitter Synthesizer, 800-375B 1
C1 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 1
C3 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 1
C4 Capacitor,Tantalum,SMT,size D, 47uF,16V Kemet T491D476K016AS 298-476 1
C5 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C6 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C7 Capacitor,Tantalum,SMT,size D, 47uF,16V Kemet T491D476K016AS 298-476 1
C8 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C9 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C10 Capacitor,Tantalum,SMT,size D, 15uF,25V Kemet T491D156K025AS 298-156 1
C11 Capacitor,Tantalum,SMT,size X,150uF,16V Kemet T491X157K016AS 298-157 1
C12 Capacitor,Tantalum,SMT,size D, 15uF,25V Kemet T491D156K025AS 298-156 1
C13 Capacitor,Tantalum,SMT,size X,150uF,16V Kemet T491X157K016AS 298-157 1
C14,C15 Capacitor, Monolithic Chip 100000pF 1% C1206C104J5RAC Kemet 270-104 2
C16 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C17 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 1
C18 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C19 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C20 Capacitor, Monolithic Chip 100000pF 1% C1206C104J5RAC Kemet 270-104 1
C21 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C22,C23 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 2
C24 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C25 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C26 Capacitor, monolithic chip, 10 pf 50v Kemet C1206C100J5GACTR 270-100 1
C27-C29 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 3
C30 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C31 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C32 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C33 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C34 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C35 Capacitor, Monolithic Chip 100000pF 1% C1206C104J5RAC Kemet 270-104 1
C36 Capacitor,Tantalum,SMT,size D, 47uF,16V Kemet T491D476K016AS 298-476 1
C38 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C39 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C40 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 1
C41 Cap., Tantalum, SMT, Size B, 10uF, 16V,Kemet T491B106K016AS 298-106 1
C42 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C43 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C44,C45 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 2
C50,C51 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 2
C52 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C53 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 1
C54 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
C55 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 1
C56 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
