P/N 800-375AT
(see legend below for xx(x) and yy)
Transmitter Synthesizer
Board Assy
1/10/03
C57,C58 Capacitor,monolithic chip,33 pf 50v 5% Kemet C1206C330J5GAC 270-330 2
C59,C60 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 2
C61 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C62 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
D1 Diode, Zener, SMT, 13V, Vishay BZX84C13TR 415-840 1
D2 Diode, SMT, Zener, 5.1V Motorola BZX84C5V1LT1 418-451 1
D3 Diode, SMT, Zener, 4.7V, Motorola BZX84C4V7LT1 418-447 1
D4 Diode, SMT, Zener, 5.1V Motorola BZX84C5V1LT1 418-451 1
J1 Connector, S.FL2-R-SMT surface mount Hirose 550-193 1
L1-L3 Inductor, 10uH SMT DN12103JTR-ND DELEVAN 5% 330-024 3
L4,L5 Inductor, SMT, 1008, 330nH, Coilcraft 1008CS-331XKBC 350-191 2
L6-L9 Inductor, 10uH SMT DN12103JTR-ND DELEVAN 5% 330-024 4
P1 Conn,16-Pin (cut from 550-325) Right Angle 550-325-16 1
P2 Conn,20-Pin (cut from 550-325) Right Angle 550-325-20 1
Q1-Q5 Transistor, SMT, Darlington, NPN, Mototrola MMBTA14LT1 420-141 5
Q7-Q9 Transistor, SMT, General Purpose,NPN, Motorola MMBT3904LT1 439-041 3
R1 Resistor, SMT, size 1206, 2.74K ohms, Dale CRCW1206-2.74K 185-2.74K 1
R2 Resistor, SMT, size 1206, 5.11K ohms, Dale CRCW1206-5.11K 185-5.11K 1
R3 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 1
R4 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 1
R5 Resistor, SMT, size 1206, 22.1 ohms, Dale CRCW1206-22.1 185-22.1 1
R6,R7 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 2
R8 Resistor, 10K ohm 1/8 watt 1% chip Dale CRCW1206-10K 185-103 1
R11 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 1
R13 Resistor, 10K ohm 1/8 watt 1% chip Dale CRCW1206-10K 185-103 1
R14 Resistor, SMT, size 1206, 432 ohms, Dale CRCW1206-432 185-432 1
R15 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 1
R16 Resistor, Dale CRCW1206-100K 100k ohm 1/8 watt 1% chip 185-104 1
R17 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 1
R18 Resistor, 10 Ohm Dale CRCW1206-10 1% Tape & Reel 185-100 1
R19 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 1
R20 Resistor, 10K ohm 1/8 watt 1% chip Dale CRCW1206-10K 185-103 1
R21-R23 Resistor, SMT, size 1206, 18.2 ohms, Dale CRCW1206-18.2 185-18.2 3
R24,R25 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 2
R26* Capacitor, monolithic chip, 10 pf 50v Kemet C1206C100J5GACTR 270-100 1
* - Yes, this is a capacitor; Removed for 950 model frequency band
R27 Resistor, 15 ohm 1/8 watt 5% chip Dale #CRCW1206150JT 185-150 1
R28,R29 Resistor, SMT, size 1206, 39.2 ohms, Dale CRCW1206-39.2 185-39.2 2
R30 Resistor, SMT, size 1206, 2.74K ohms, Dale CRCW1206-2.74K 185-2.74K 1
R31,R32 Resistor, SMT, size 1206, 5.11K ohms, Dale CRCW1206-5.11K 185-5.11K 2
R33 Resistor, 1K ohm 1/8 watt 1% chip Dale CRCW1206-1K 185-102 1
R34 Resistor, SMT, size 1206, 47.5 ohms, Dale CRCW1206-47.5 185-47.5 1
R35,R36 Resistor, 10 Ohm Dale CRCW1206-10 1% Tape & Reel 185-100 2
R37 Resistor, SMT, size 1206, 133 ohms, Dale CRCW1206-133 185-133 1
R38 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R43 Resistor, SMT, 1206, 51.1 ohm, Dale CRCW1206-51.1 185-51.1 1
R44 Resistor, SMT, 1206, 3.32K, Dale CRCW1206-3.32K 185-3.32K 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
2
