P/N 800-388Axxx-yy
or 800-373Axxx-yy
(see legend below for xx(x) and yy)
PA ASSY,
xxx MHZ, yyW
1/10/03
SYMBOL DESCRIPTION PART NUMBER QTY
SCREW,SEMS 6-32 X 7/16" PAN PH.ST. 422-6107 2
#4 FLAT SS .250 X .125 X .018 423-4001 3
Screw, 4-40 x 1/2" phillips pan head M/S nickel plated 500-011 5
Lockwasher, #4 internal tooth small pattern zinc plated 500-055 5
Screw, SEMS 4-40x3/8 Phillips Pan Head MS Black Zinc 500-211 3
Spacer, 4-40 x 3/8 hex threaded Keystone 1450B 513-022 5
Heatsink, Drilled for Revised STL-10/15C Rev B 520-050D5 1
Thermalcote, Thermalloy #251 1# container 920-003 0
ASSY., THERMOCOUPLE 959-0321 1
Washer, TO-220 Shoulder NYL Thermalloy #7721-7PPS DB61024 3
388 only TWO-STAGE RF PA BOARD ASSEMBLY 800-388A 1
373 only TWO-STAGE RF PA BOARD ASSEMBLY 800-373A 1
INS1 INSULATOR,MICA,TO-220,56-77-11 407-0036
INS2 INSULATOR,MICA,TO-220,56-77-11 407-0036 1
INS3 INSULATOR,MICA,TO-220,56-77-11 407-0036 1
U5-U7 Integated Circuit,SMT,Regulator,5 amp,National LM338T 401-338 3
150 MHz Band, 30W Model
C35-C37 Capacitor, SMT, 18 pF, 100V 270-180-1 3
D1,D2 Not Used
L8 Inductor, SMT, 1812, 56 nH 350-200 1
L9,L10 Inductor, SMT, 1812, 82 nH 350-201 2
L11 Inductor, SMT, 1812, 56 nH 350-200 1
R1 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R11 Resistor, #263-47k ohm 1/8 watt 5% chip 185-47.5K 1
U3 IC, PA MODULE, 135-185 MHZ, 30W 467-741 1
150 MHz Band, 60W Model
C35-C37 Capacitor, SMT, 18 pF, 100V 270-180-1 3
D1,D2 Not Used
L8 Inductor, SMT, 1812, 56 nH 350-200 1
L9,L10 Inductor, SMT, 1812, 82 nH 350-201 2
L11 Inductor, SMT, 1812, 56 nH 350-200 1
R1 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R11 Resistor, SMT, 1206, 22.1K 185-22.1k 1
U3 IC, PA MODULE, 135-185 MHZ, 60W 468-702 1
230 MHz Band, 30W Model
C35-C37 Capacitor, SMT, 12 pF, 100V 270-120 3
D1,D2 Not Used
L8 Inductor, SMT, 1812, 39 nH 350-202 1
L9,L10 Inductor, SMT, 1812, 56 nH 350-200 2
L11 Inductor, SMT, 1812, 39 nH 350-202 1
R1 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R11 Resistor, SMT, 1206, 22.1K 185-22.1k 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50 or 60
depending on
model MAX power
1
