Marti Electronics SRPT-40A - Page 85

P/N 800-388Axxx-yy
or 800-373Axxx-yy
(see legend below for xx(x) and yy)
PA ASSY,
xxx MHZ, yyW
1/10/03
U3 IC, PA MODULE, 215-250 MHZ, 30W 468-729 1
250 MHz Band, 30W Model
C35-C37 Capacitor, SMT, 10 pF, 100V 270-100-1 3
D1,D2 Not Used
L8 Inductor, SMT, 1812, 33 nH 350-203 1
L9,L10 Inductor, SMT, 1812, 47 nH 350-204 2
L11 Inductor, SMT, 1812, 33 nH 350-203 1
R1 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R11 Resistor, SMT, 1206, 22.1K 185-22.1k 1
U3 IC, PA MODULE, 235-265 MHZ, 30W 468-706 1
330 MHz Band, 30W Model
C35-C37 Capacitor, SMT, 6.8 pF, 100V 270-608-1 3
D1,D2 Not Used
L8 Inductor, SMT, 1812, 22 nH 350-204 1
L9,L10 Inductor, SMT, 1812, 33 nH 350-203 2
L11 Inductor, SMT, 1812, 22 nH 350-204 1
R1 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R11 Resistor, SMT, 1206, 22.1K 185-22.1k 1
U3 IC, PA MODULE, 300-350 MHZ, 30W 457-729 1
450 MHz Band, 30W Model
C35-C37 Capacitor, SMT, 4.7 pF, 100V 270-407-1 3
D1,D2 Not Used
L8 Inductor, SMT, 1206, 12.5 nH 350-192 1
L9,L10 Inductor, SMT, 1206, 18.5 nH 350-194 2
L11 Inductor, SMT, 1206, 12.5 nH 350-192 1
R1 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R11 Resistor, SMT, 1206, 22.1K 185-22.1k 1
U3 IC, PA MODULE, 430-480 MHZ, 30W 468-762 1
450 MHz Band, 60W Model
C35-C37 Capacitor, SMT, 4.7 pF, 100V 270-407-1 3
D1,D2 Not Used
L8 Inductor, SMT, 1206, 12.5 nH 350-192 1
L9,L10 Inductor, SMT, 1206, 18.5 nH 350-194 2
L11 Inductor, SMT, 1206, 12.5 nH 350-192 1
R1 Resistor,0 Ohm 1206 Chip Mfg# DALCRCW1206000ZT-X 185-000 1
R11 Resistor, SMT, 1206, 22.1K 185-22.1k 1
U3 IC, PA MODULE, 430-480 MHZ, 60W 468-703 1
950 MHz Band, 20W Model
C35-C37 Capacitor, SMT, 2.2 pF, 50V 270-202 3
D1,D2 Diode, Zener, SMT, 4.3V 415-916 2
L8 Inductor, SMT, 1206, 5 nH 350-198 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50 or 60
depending on
model MAX power
2
