BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 40

…………
 ±0.0208msperclick,or
 ±0.007mperclick,or
 ±0.023feetperclick

TurningtheseControlsclockw ise increasesthedelaytime,whileturningthemanti‐clockwisedecreasesthedelaytime.
Theminimumandmaximumdelayrangesfrom:
 0.0000ms–600.9984ms
 0.000m–204.
339m
 0.000feet–670.233feet

PresstheESCbutton[11]toexitdelayeditingmode.
HighPassFilter
HighPassFiltersareutilizedtosetup crossoversinmulti‐wa y loudspeakerandsubwoofersystems.Theymayalsobeusedto
roll‐offlowfrequenciesthatfull‐rangeloudspeakerscannotefficientlyreproduce.
UsetheEdit2[8]Controltochangethefrequency.Turningthiscontrolclockwiseincreasesthefrequency,whileturningitanti‐
clockwisedecre
asesthefrequency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
TurntheEdit3[9]Controltoseethevariousfiltertypeandslopeoptions:
 NoCut‐Off
 Butterworth6dB
 Butterworth12dB
 Linkwitz‐Riley12dB
 Bessel12dB
 Butterworth18dB
 Butterworth24dB
 Linkw
itz‐Riley24dB
 Bessel24dB

PresstheESCbutton[11]toexitthiseditmode.
LowPassFilter
Inconjunction withhighpassfilters,lowpassfiltersareutilizedtosetupcrossoversinmulti‐wayloudspeakerandsubwoofer
systems.Forexample,ina3‐waystereosystem,use thehighandlowpassfiltersontheoutputfeedingthemid‐rangetransducer
todefinetherangeoffrequenciesitwillreproduce.Com
binedwithhighand lowpassfiltersontheoutputstothelowandhigh
frequencytransducers,youmaydividethefrequencyspectrumsoeachtransducerisreproducingtherangeforwhichitisbest
suited,makingthesystemsounditsbestandoperatemostefficiently.
UsetheEdit2[8]Co
ntroltochangethefreque ncy.Turningthiscontrolclockwiseincreasesthefrequency,whileturningitanti‐
clockwisedecreasesthefrequency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
TurntheEdit3[9]Controltoseethevariousfiltertypeandslopeoptions:
 NoCut‐Off
 Butterworth6dB
 Butterworth12dB
 Linkw
itz‐Riley12dB
 Bessel12dB
 Butterworth18dB
 Butterworth24dB
 Linkwitz‐Riley24dB
 Bessel24dB

PresstheESCbutton[11]toexitthiseditmode.
Limiter
