EM150
TYPE Ultra compact sub-bass system
FREQUENCY RESPONSE 45Hz-200Hz ± 3db
RATED POWER 400W AES, 1600W peak
(2 x 200W AES, 800W peak per driver)
SENSITIVITY 98dB
MAXIMUM SPL 123dB continuous, 129dB peak
RECOMMENDED AMPLIFIER 400-500W (into 4 ohms)
NOMINAL IMPEDANCE 2 x 8 ohms nominal stereo,
4 ohms nominal mono
BASS 2 x 250mm (10") extended throw
ENCLOSURE 91 litres, vented
CONNECTOR 2 x spring-loaded
DIMENSIONS (W) 790mm x (H) 360mm x (D) 410mm
(W) 31.1ins x (H) 14.2ins x (D) 16.1ins
WEIGHT 31kg (68lbs)
SHIPPING DIMENSIONS (W) 950mm x (H) 390mm x (D) 450mm
(W) 37.4ins x (H) 15.4ins x (D) 17.7ins
SHIPPING WEIGHT 34kg (75lbs)
NO
TES (EM Series)
Sensitivity measured in half-space conditions at 1 metre with 1 watt input,
using band limited pink noise. SPL measured at 1 metre using band limited
pink noise.
Finish: Textured grey green paint.
Protective grilles: Perforated steel grey with 48% free air flow.
Due to our policy of continuous improvement all specifications are subject
to change without notice.
Martin Audio – EM SERIES
ENGLISH
9
