9 TECHNICAL SPECIFICATIONS
EM15
TYPE Ultra compact, two-way ICT™
FREQUENCY RESPONSE 120Hz-20kHz ±3dB
RATED POWER 75W AES, 300W peak
SENSITIVITY 91dB
MAXIMUM SPL 108dB continuous, 114dB peak
RECOMMENDED AMPLIFIER 50-100W (into 4 ohms)
DISPERSION 80 degs horizontal x 80 degs vertical
NOMINAL IMPEDANCE 4 ohms (16 ohms optional/user
configurable)
BASS 5” (125mm)
HIGH FREQUENCY 5” (125mm) ICT™
ENCLOSURE 5 litres, rear vented
CONNECTOR Spring-loaded
FITTINGS M4 inserts for Omnimount 50
DIMENSIONS (W) 172mm x (H) 282mm x (D) 172mm
(W) 6.8ins x (H) 11ins x (D) 6.8ins
WEIGHT 5kg (11lbs)
SHIPPING DIMENSIONS (W) 390mm x (H) 370mm x (D) 200mm
(Packed in pairs) (W) 15.4ins x (H) 14.5ins x (D) 7.9ins
SHIPPING WEIGHT 9kg (19.8lbs)
(Packed in pairs)
Martin Audio – EM SERIES
ENGLISH
