Martin MX-4 - DMX PROTOCOL

DMX protocol 23
DMX PROTOCOL A
Channel Value Percent Function
1
0 - 9
10 - 19
20 - 99
100 - 159
160 - 179
180 - 204
205 - 229
230 - 239
240 - 249
250 - 255
0 - 3
3 - 7
7 - 39
39 - 62
63 - 70
70 - 80
80 - 90
90 - 94
94 - 98
98 - 100
Shutter, Lamp power, Reset
Shutter closed (blackout)
Lamp-on
Shutter open
Strobe, fast to slow
Shutter closed
Remote stand-alone w/ music trigger
Remote stand-alone w/ auto trigger
Shutter closed
Reset (hold for 5 sec.)
Lamp-off (w/ ch. 2 & 3 > 252, hold for 5 sec.)
2
0 - 5
6 - 11
12 - 17
18 - 23
24 - 29
30 - 35
36 - 41
42 - 47
48 - 53
54 - 59
60 - 65
66 - 71
72 - 77
78 - 83
84 - 89
90 - 95
96 - 101
102 - 107
108 - 113
114 - 119
120 - 125
126 - 131
132 - 137
138 - 143
144 - 149
150 - 155
156 - 161
162 - 167
168 - 173
174 - 179
180 - 185
186 - 191
192 - 197
198 - 203
204 - 209
210 - 255
0-1
2-4
4-6
7-9
9-11
11-13
14-16
16-18
18-20
21-23
23-25
26-27
28-30
30-32
33-35
35-37
37-39
40-42
42-44
44-46
47-49
49-51
52-53
54-56
56-58
59-61
61-63
63-65
66-68
68-70
70-72
73-75
75-77
78-79
80-82
82-100
Color wheel
White
White / Light blue 101
Light blue 101
Light blue 101 / Fern green 205
Fern green 205
Fern green 205 / Red 304
Red 304
Red 304 / Yellow 603
Yel low 60 3
Yellow 603 / Magenta 507
Magenta 507
Magenta 507 / Medium blue 108
Medium blue 108
Medium blue 108 / Deep orange 302
Deep orange 302
Deep orange 302 / Light green 204
Light green 204
Light green 204 / Cyan 104
Cyan 104
Cyan 104 / Pink 312
Pink 312
Pink 312 / Blue 111
Blue 111
Blue 111 / Amber 604
Amber 604
Amber 604 / Primary red 308
Primary red 308
Primary red 308 / Primary green 206
Primary green 206
Primary green 206 / Orange 306
Orange 306
Orange 306 / Split-color 1
Split-color 1
Split-color 1 / Split-color 2
Split-color 2
Remote stand-alone action, select trigger on ch. 1
