MC-1 operation
MC-1
OPERATION
5
The MX-4 is fully compatible with the Martin MC-1 Controller. See the MC-1 user
manual for additional information.
SETTINGS
DIP-switch pin 10 must be set to OFF to enable MC-1 mode operation. Changes to
the setting take effect after the fixture has been turned off and on.
DIP-switch pins 5, 6, 7, 8, and 9 select several control options that can be combined
to achieve powerful effects quickly and easily.
Option Setting (0 = OFF, 1 = ON)
1234567891011
wide pan/tilt 1 0
inverted color 1 0
inverted gobo 1 0
inverted tilt 1 0
inverted pan 1 0
