Martin SB6000 - Page 15

CHIMNEY INSTALLATION
14
IMAGINARY
CENTER POINT
ACTUAL
CENTER POINT
CENTERLINE 
OF CHIMNEY
PLUMB BOB
PLUMB LINE
TABLE 1
MINIMUM REQUIRED ROOF OPENING
MINIMUM FRAMED OPENING
"L" SERIES 
DOUBLEWALL CHIMNEY
DOUBLEWALL CHIMNEY

17" x 17"
17" x 17" 1/8"
17" x 17" 1/4"
17" x 17" 1/2"
17" x 17" 3/4"
17" x 18" 1/4"
17" x 18" 3/4"
17" x 19" 3/8"
17" x 20"
17" x 20" 5/8"
17" x 21" 3/8"
17" x 22" 1/4"
17" x 23"


ROOF PITCH

0/12
1 12
2/12
3 12
4/12
5 12
6/12
7 12 
8/12
9 12
10/12
11 12 
12 12
INSTALLATION OF FIRESTOP-SPACER AT FLOOR LEVELS
INSTALLATION OF FIRESTOP-SPACER AT FLOOR LEVELS
INSTALLATION OF FIRESTOP-SPACER AT ATTIC LEVEL
INSTALLATION OF FIRESTOP-SPACER AT ATTIC LEVEL
FLUE PIPE
FLUE PIPE
FIRESTOP SPACER
FLOOR JOIST
HEADER
CHIMNEY SECTION
INLET AIR PIPE
FIRESTOP SPACER
CHIMNEY SECTION
CEILING JOIST
INLET AIR PIPE
HEADER
OUTER PIPE
FLUE
SUPPORT STRAPS 
FASTEN SECURELY
FIRESTOP
CHIMNEY 
SUPPORT
SNAP LOCK CHIMNEY
SUPPORT SECURELY 
TO LOWER PIPES 
BEFORE FASTENING
SUPPORT STRAPS
FIGURE 16
FIGURE 17
FIGURE 18
53D9027. Rev 1 03/03
