Martin SB6000 - Parts Diagram and List

10
9
8
7
6
5
4
3
2
1
SB6000
PART NO.
PART NO.
047647
072935
072939
071476
072954
047649
071474
073716
N/A
071475
QTY.
QTY.
1
1
2
2
1
1
1
1
1
1
PART NAME (NOUN FIRST)
PART NAME (NOUN FIRST)
ROD DAMPER
ROD DAMPER
WELDMENT OSA ROD/PLATE
WELDMENT OSA ROD/PLATE
PANEL FIRE SCREEN W/PULL
PANEL FIRE SCREEN W/PULL
FIRE BRICK SIDE ASSEMBLY
FIRE BRICK SIDE ASSEMBLY
GRATE PAINTED ASSEMBLY
GRATE PAINTED ASSEMBLY
WELDMENT DAMPER WEIGHT
WELDMENT DAMPER WEIGHT
FIRE BRICK BACK ASSEMBLY
FIRE BRICK BACK ASSEMBLY
HANDLE DAMPER
HANDLE DAMPER
FIRE BRICK, RT SIDE ASSEMBLY
FIRE BRICK, RT SIDE ASSEMBLY
HEARTH REFRACTORY
HEARTH REFRACTORY
KEY 
NO.
NO.
1
2
3
4 
5
6
7
8
9
10
31
PARTS DIAGRAM AND LIST
FIGURE 27
All repair part orders should be placed through your local dealer. To ensure prompt and accurate service,
please provide the following information when placing a repair part order: Model number of your Appliance,
Part Name, Part Number, and Quantity of parts needed.
Technical Service Department
2813 W. Mall Drive, Unit B.
Florence, Alabama 35630.
Tel. - 1-866-500-5671
www.martinhearthandheating.com
53D9027. Rev 1 03/03
