12-6
SUPPLEMENTARY FOR AMBULANCE (EECO CARE)
78L15-74E
FIRE EXTINGUISHER
CLAMPS
78LM14013
Provision for keeping 2kg fire extinguisher
is provided on the floor between driver
seat and attendant seat.
78LM14015
For removal of fire extinguisher, lift the
lever (1) slightly upwards and pull the fire
extinguisher in the direction as shown in
the above figure, in order to disengage it
from clamp (2).
78LM14019
For fitment of fire extinguisher, insert the
body of fire extinguisher (3) in to the clamp
(2) and place the nozzle carefully down-
wards, on the clamp.
NOTE:
• Ensure that the nozzle of fire extin-
guisher is facing downwards properly
seated on the clamp.
• Ensure that the Fire extinguisher is
always kept at its prescribed position in
the vehicle.
(2)
(1)
(2)
(3)
