MARUTI SUZUKI EECO User Manual

8-13
INSPECTION AND MAINTENANCE
76MH1-74E
AIR CLEANER
09-76A064A
If the air cleaner is clogged with dust,
intake resistance will be increased with a
resultant decrease in power output and
increase in fuel consumption.
Check and clean periodically according to
the following procedure:
1) Take off the air cleaner case cover.
Remove the element from the air
cleaner case cover.
2) This air cleaner element is of dry type.
Remember that it needs cleaning
according to the following method.
3) Blow off dust on cleaner element by
compressed air from inside the ele-
ment, or replace the element as neces-
sary.
SPARK PLUGS
09-76A007A
You should inspect spark plugs periodically
for carbon deposits. When carbon accu-
mulates on a spark plug, a strong spark
may not be produced. Remove carbon
deposits with a wire or pin and adjust the
spark plug gap.
09-76A008A
To access the spark plugs,
1) Disconnect the coupler while pushing
the release lever,
2) Remove the bolts, and
3) Pull the spark plug boots.
09-76A009A
Spark plug Tightening torque
20.0 - 30.0 N-m
(2.0 - 3.0 kg-m, 15.0-22.0 lb-ft)
EXAMPLE
EXAMPLE
CORRECT
WRONG
EXAMPLE
CAUTION
When disconnecting the spark plug
cables, pull on the boot, not on the
cable itself. Pulling on the cable can
damage it.
CAUTION
• When installing the spark plugs,
screw them in with your fingers to
avoid stripping the threads.
Tighten with a torque wrench to the
specified torque. Do not allow con-
taminants to enter the engine
through the spark plug holes when
the plugs are removed.
• Never use spark plugs with the
wrong thread size.
TIGHTEN
LOOSEN
EXAMPLE
