Maruyama BL3100 - Specifications

— 26 —
Emission durability of 300 hours.
※
1. Dry weight without Pipe A and B
Model BL3100
Dimensions L x W x H 12.8 x 10.0 x 14.6in (325 x 255 x x370mm)
Dry Weight
※
1 9.5lbs (4.3 Kg)
Engine Displacement 30.1 cm
3
Ignition System Solid State
Carburetor Walbro Diaphragm Type
Fuel Tank Capacity 0.53 qts. (0.5 )
Gas to Oil Ratio 50:1
Spark Plug NGK BPM6Y
Spark Plug Gap .024 -.028 in (0.6 - 0.7 mm)
CARB Approved Tier 3
Specifications
