— 5 —
English
Standard
BEFORE OPERATION
Be sure the power blower is correctly assembled and all fasteners and fittings are properly secured.
THROTTLE LEVER
Standar
d
Before operating the power blower, release the knob, knove the throttle grip to the position in the
illustration, and tighten knob to secure in place.
When the power blower is strapped to the back of the operator, the throttle lever of is located on the
tube.
SHOULDER
STRAPS
SERIAL NUMBER
(BLOWER HOUSING)
BACK PAD
HIP BELT
Accessories
RECOIL STARTER
ENGINE
BLOWER HOUSING
BAND
AIR CLEANER
PRIMER BULB
RETURN PIPE
FUEL TANK
FLEXIBLE PIPE
SWIVEL PIPE
BENT PIPE
STRAIGHT PIPE
THROTTLE LEVER
CLAMP
THROTTLE
LEVER
KNOB
