Water Supply
The ice machine must be connected to a potable, active
cold water supply line delivering water pressure at a mini-
mum of 20 psi and a maximum of 120 psi.
Water connection is made through a right angle •
garden hose fitting supplied with the ice machine. See
Figure 10 for detailed instructions. DO NOT USE ANY
THREAD SEALERS.
A water filter can be used with this unit. A quality filter •
can help remove particles as well as remove taste and
odors from water.
DO NOT USE A “REVERSE OSMOSIS” FILTERING •
DEVICE.
Softened water is not recommended. This will produce •
soft, cloudy ice cubes that will stick together.
De-ionized water is not recommended. This water will •
not form solid ice cubes.
A water specialist can recommend proper water treat-•
ment.
After installation of water line, turn on water and check •
for any leaks. Additional tightening may be needed.
Allow for extra water line for built-in installations for •
easy removal of unit and to help prevent the water line
from kinking.
CONNECTING THE WATER SUPPLY
7
Figure 9
From Water Supply
to Ice Maker
1/4 inch Copper
Water Supply Line (*)
Fitting Valve
Adapter
Rubber Washer
Compression Fitting
Compression Nut
(*) Supplied by Customer
The water line fitting supplied with your icemaker is to be used
on a 1/4 inch copper water supply line only. Do not attach a
plastic supply line using this fitting.
Figure 10
NOTE
1/4 inch
Tubing from
Cold Water Line
Garden Hose
Fitting
Compression Fitting
5-1/2”
(140mm)
2-7/32” (57mm)
