CARE AND CLEANING
position on the light enclosure’s flange. Reuse the original
two screws to secure it in place. Plug the wine cellar into
the electrical socket. Check to see if the light tube operates
properly. Your light tube’s replacement is complete.
For model 6SDZE:
This product uses two, 6 watt light tubes to illuminate the
interior of the dual zone wine cellar: one in the upper com-
partment and one in the lower compartment. The upper
compartment light tube is located behind the display hous-
ing. The lower compartment light tube is located on the
underside of the divider that separates the compartments.
To replace the light tube, disconnect power to the unit.
Use a hex-head driver to remove the two hex-head screws
holding the old light tube in place. Disconnect the electri-
cal plug from the cabinet’s electrical receptacle and discard
the old light tube. Reconnect the electrical plug of the new
light tube to the cabinet’s electrical receptacle. Make sure
it is secure and fully installed.
Using the hex-head driver, resecure the two hex-head
screws to secure the light tube in place. Plug the unit into
the electrical socket. Check to see if the light tube operates
properly. Your light tube’s replacement is complete.
The light tubes are not covered by your warranty. Replace-
ment tubes can be obtained from your dealer or from
Northland-Marvel.
In the Event of a Power Failure
If a power failure occurs, try to correct it as soon as pos-
sible. Minimize the number of door openings while the
power is off so as not to adversely affect the unit’s tem-
perature.
22
Light Tube Replacement
DISCONNECT THE POWER CORD BEFORE ATTEMPTING
LIGHT TUBE REPLACEMENT. Failure to do so may result in
an electrical shock that could severely injure you.
The 3SWCE and 3SWCCE uses one, 6 watt light tube and
the 6SWCE, 6SDZE, and 8SWCE use two, 6 watt light tubes
to illuminate the interior of the wine cellar. The light tube
is a very reliable electrical component, but should it not
function properly, please call the dealer you purchased your
wine cellar from for a replacement light tube. Use only an
original equipment light tube from your dealer or North-
land-Marvel.
It may be necessary to remove 1 or 2 shelves directly below
the light tube to gain access for removal. See page 21 for
instructions on removing the shelves.
Do NOT under any circumstance use a light tube that ex-
ceeds 10 watts!
All models except 6SDZE:
To replace a light tube, use a hex-head driver, remove the
two hex-head screws that hold a cover plate over the back
section of the light tube. Set the screws and cover plate
aside for reassembly later.
Using a small flat-blade screwdriver, gently lever the front
section of the light tube down to allow it to be pulled clear of
the light housing.
Disconnect the two insulated electrical connectors from the
cabinet’s electrical cable and discard the old light tube. Re-
connect the electrical connector of the new light tube to the
cabinet’s electrical cable connectors. Make sure it is secure
and fully installed.
Carefully realign the light tube’s electrical terminal back into
the rear of the light enclosure channel making sure not to
crimp them. Gently insert the light tube along the length of
the light enclosure channel. Press the light tube gently into
the light enclosure channel. Only a small part of the light
tube should project below the ceiling of the wine cellar. DO
NOT USE A HAMMER TO FIT THE LIGHT TUBE.
Place the light tube terminal cover plate back in the original
