Marvel MSNP115-SS01A - Page 14

14
CUTOUT & PRODUCT DIMENSIONS
CUTOUT DIMENSIONS - MLNP115
PRODUCT DIMENSIONS
REAR
1 1⁄₂" (38 mm)
7"
(178 mm)
15 1⁄4"*
(387 mm)
34 1⁄₄"
(870 mm)
to
35 1⁄₄"
(889 mm)
Preferred location
for electrical outlet
is in an adjacent
cabinet.
24"
(610 mm)
5⁄8"
(16 mm)
Figure 31
2”
(51 mm)
4”
(102 mm)
Water Line
Drain
7 ½ ”
(191 mm)
3 ⁄ ”
(80 mm)
4”
(102 mm)
7 ½ ”
(191 mm)
Power Cord
6 ft (183 cm)
Figure 32
FRONT
TOP
SIDE
14 ⁄”
(379 mm)
3 ½”
(89 mm)
28”
(711 mm)
33 ⁄”
to 34 ⁄”
(855 mm
to
881 mm)
Figure 33
1 ⁄”
(48 mm)
17 ½”
(445 mm)
21 ⁄”
(535 mm)
Figure 34
10 ⁄”
(260 mm)
22 ⁄”
(583 mm)
24 ⁄”
(630 mm)
4 ⁄ “ (111 mm)
Figure 35
