Mase 2500 M - WIRING DIAGRAMS; Model-Specific Wiring Diagrams

FMMASE
16
WIRING DIAGRAM
FM 2500 M
1 Diode 25 A 800 V
2 Varistor
3 Rotor
4 Capacitor
5 Stator
6 Generator warning light
7 A.C. socket switch
8 Thermal Switch
9 Socket 16A
FM 4000 M
1 Diode 25 A 800 V
2 Varistor
3 Rotor
4 Capacitor
5 Stator
6 Generator warning light
7 A.C. socket switch
8 Thermal Switch
9 Socket 16A
10 ON-OFF switch
FM 5600 M
1 Diode 25 A 800 V
2 Varistor
3 Rotor
4 Capacitor
5 Stator
6 Generator warning light
7 A.C. socket switch
8 Thermal Switch
9 Thermal Switch
10 Socket 16A
11 Socket 32A
12 ON-OFF switch
FM 6000 T
1 Rotor
2 Stator
3 Electronic regulator
4 A.C. socket switch
5 Magnetothermal switch
6 Thermal Switch
7 Socket 16A
8 Socket 16A
9 ON-OFF switch
10 Generator warning light
FM 8000 M
1 Rotor
2 Stator
3 Diode 25 A 400 V
4 Hours Meter
5 Fuse 10A
6 Thermal Switch
7 Socket 16A
8 Capacitor
9 Stop buton
10 Diode 20A 800V
11 Varistor
