Adjustment of carburetor idle speed RPM
1.
Start the engine and allow it to fully warmed-up without load.
2.
Close the accelerator. Rotate the idle adjusting screw to keep the engine
running at 1400±100 rpm.
Adjustment of accelerator wire
1.
Locking nut 2. Adjuster
1.
Loosen the locking nut.
2.
Rotate the adjuster to make the wire clearance between 0.5 - 1.0 mm.
3.
After clearance adjustment, tighten the locking nut once again.
Warning
Idle speed adjustment shall be carried out while the engine is fully
warmed up.
