Adjustment of clutch
Clutch adjustment is made through adjusting the tension of wire rope for
clutch grip. Before feeling the gear disengagement by pressing the clutch grip,
the wire clearance measured at clutch grip shall be 4 mm. If the clutch wire
clearance is found incorrect, carry out adjustment as follows.
Loosen the nut (1) and adjust the tension by turning the tension ring of the
lever (2) clockwise. Once the adjustment has been made, tighten the lock nut
(1), then wrap them with the rubber sleeve (3).
Warning
After accelerator wire adjustment, check the operation of accelerator grip.
Engine idle speed shall not increase due to the adjustment, and the grip shall
return to the closed position automatically.
